SECTION 7 - ENDMARKER SERVICE
page 7-4
SDX30 ENDMARKER
ASSEMBLY
REF DESCRIPTION REF DESCRIPTION
1 NUT .625 UNC GR5 YZD 16 SPRING, TENSION .406 WIRE
2 NUT, LOCK .438 UNC GR B YZD 17 PIN, PIVOT CHROME HORIZONTAL
3 WASHER, LOCK .625 YZD 18 SPACER TUBE SPRING BIAS EM
4 NUT, LOCK .625 UNC GR B YZD 19 SPACER TUBE HORIZ PIVOT EM
5 CAPSCREW .5 X 3.5 UNC GR5 YZD 20 SPRING, TENSION BRACKET EM
6 CAPSCREW .438 X 2.5 UNC GR5 YZD 21 BOLT .75 X 15 ALL THREAD YZD
7 CAPSCREW .625 X 2.5 UNC GR5 YZD 22 PLATE MOUNT SPRING BIAS ENDMARKER
8 PIN, LINCH HAIRPIN .243 X 4 YZD 23 KNUCKLE ASSY. SADDLE BIFOLD
ENDMARKER
9 NUT JAM .75 UNC GR5 YZD 24 ROD, CONNECTING COMPRESSION LINK
SPRG
10 BOLT US .625 7.125W 8.5D 25 SPACER STOP PLATE CUSHION SPRG
PTD
11 SPRING (COIL) - C .313 WR 1.625 OD 12.5 26 CYLINDER ASSY. 2X12 MON 3000PSI
W/PINS
12 NUT, LOCK .75 UNC YZD NYLON INS 27 ENDMARKER INNER BI-FOLD ASSY.
13 MOUNTING ENDMARKER PNTD 28 GUARD DISK PROTECTOR ENDMARKER
14 PLATE BOLTING PNTD 29 BOLT .625 X 1.5 UNC GR5 YZD
15 CAPSCREW .75 X 8.5 UNC GR8 YZD 30 LOCKNUT .5 UNC GR5 YZD
