SECTION 2 - MECHANICAL SERVICE
page 2-6
Subbar Cylinder Locks
202166S
SPECIFICATIONS
IMPLEMENT DIMENSIONS
MODEL DRILL
SPACING
number
of
openers
WORKING
WIDTH
TRANSPORT LENGTH WEIGHT
WIDTH HEIGHT CLEARANCE
SDX30 19.1 cm
(7.5")
48 9.1 m
(30')
4.27 m
(14')
3.561 m
(11'6")
20 cm
(8")
8.5 m
(27' 10")
10,900 kg
(24,000 lb)
25.4 cm
(10")
36 9.1 m
(30')
4.42 m
(14'6")
3.561 m
(11'6")
20 cm
(8")
8.5 m
(27' 10")
7,800 kg
(17,000 lb)
SDX40 19.1 cm
(7.5")
64 12.19 m
(40')
5.08 m
(16' 8")
4.78 m
(15' 8")
20 cm
(8")
8.5 m
(27' 10")
13,800 kg
(30,500 lb)
25.4 cm
(10")
48 12.19 m
(40')
5.16 m
(16' 11")
4.78 m
(15' 8")
20 cm
(8")
8.5 m
(27' 10")
11,600 kg
(26,600 lb)
38.1 cm
(15")
33 12.19 m
(40')
5.16 m
(16' 11")
4.78 m
(15' 8")
20 cm
(8”)
8.5 m
(27' 2")
10,390 kg
(22,900 lb)
LOCKING OPENERS / SUBBAR FOR SERVICE
When servicing openers or working near the machine,
install the subbar cylinder lock on each subbar hydraulic
cylinder.
