SECTION 1 - SAFETY
page 1-16
SDX40 TRANSPORT LIGHTING AND REFLECTOR DECALS
REF DESCRIPTION REF DESCRIPTION
1 NUT .5 UNC GR5 YZD 18 BOLT .375 X 1 UNC GR5 YZD
2 WASHER, LOCK .5 YZD 19 BOLT .75 X 2.5 UNC GR5 YZD
3 LIGHT ASSY. TAIL/SIGNAL RED 20 BOLT .75 X 9 UNC GR8 YZD
4 CONSOLE IMPLEMENT LIGHTNG
CONTROL
21 BRACKET PLUG RECEPTACLE
5 BRACKET HOSE AND LIGHT 22 NUT, LOCK .25 UNC PLTD NYL INS
6 PLATE REFLECTORS 23 NUT, LOCK .75 UNC GR C YZD
7 SIGN, WARNING PLATE/A SLOW MOVING
VEHICLE
24 NUT NYLOCK: .38 NC GR6 ZP
8 BRACKET A/TRANSPORT 25 NUT, LOCK .313 UNC YZD NYL INS
9 LIGHT ASSY. WARNING 26 REFLECTOR AMBER
10 WASHER .531 X 1.062 X .095 27 REFLECTOR RED
11 WASHER .813 ID 1.5 YZD SAE 28 DECAL SDX DOWN PRESSURE CHART
12 DECAL "CASE IH" 70 MM LOGO 29 DECAL SDX WING LOCK
13 DECAL DANGER SDX OPENER LOCK 30 DECAL SDX40 LH STRIPE
14 REFLECTOR ORANGE 31 DECAL SDX40 RH STRIPE
15 NUT .5 UNF GR5 YZD 32 DECAL SMV EMBLEM
16 BOLT .25 X .75 UNC GR5 YZD 33 WASHER, LOCK .5 YZD
17 BOLT .313 X 1 UNC GR5 YZD 34 DECAL WARNING PICTORIAL
Drill Transport Lights, Reflector Decals and SMV Sign
