Case SDX30 - Nd Serial Range - Starting with Serial Number

SECTION 3 - HYDRAULIC SYSTEM SERVICE
page 3-20
SDX30 - 2
nd
SERIAL RANGE - Starting with Serial Number CBJ0007001
REF DESCRIPTION REF DESCRIPTION
1 CYLINDER ASSY. HYD 4.00 X 30.0 MON 19 BRACKET VALVE MOUNT PNT
1 CYLINDER HYD 4.00 X 30.0 MON 20 FITTING STL .5MP .5MJ BULKHD YZD
1 CYLINDER ASSY. HYD 4.00 X 30.0 IOWA 21 VALVE HYD BALL .5 FP 3000PSI
1 CYLINDER HYD 4.00 X 30.0 IOWA 22 HANDLE VALVE (Includes 60-6267T1)
2 FITTING STL .5MJ .5FJ RESTRICTOR 22 GRIP HANDLE VINYL 1 X 1.88 X3.88LG
3 CLAMP HOSE FORMED 2.88X.94PNT 23 ISOLATOR HOSE CLAMP SMALL
4 CLAMP HOSE LARGE PNT 24 ISOLATOR HOSE CLAMP LARGE
5 PIN KEEPER 25 PIN, ROLL .312 X 2 BLK HEAVY
6 PIN, COTTER HAIRPIN 3.0MM X 49.0MM
YZD
26 BOLT .375 X 1 UNC GR5 YZD
7 ADAPTER TMK#2404-8-8 27 BOLT .375 X 2 UNC GR5 YZD
8 TEE FIT STL .5MJ 28 WASHER .438 ID 1.0 .083 YZD
9 CROSS FIT STL .5MJ 29 WASHER 1.31 ID X 2.5OD X .15
10 NUT LOCK BULKHEAD .75-16 YZD 30 HOSE ASSY. HYD .375 X 144 FL
11 FITTING STL 90DEG .5MB .5MJ 31 HOSE ASSY. HYD .375 X 126 FL
12 NUT, LOCK .312-18 SER FLNGE GR.5 ZND 32 HOSE ASSY. HYD .375 X 200 FL
13 NUT NYLOCK: .38 NC GR6 ZP 33 HOSE ASSY. HYD .375 X 215 FL
14 O-RING 1/2 OD TUBE CLASS 6 34 HOSE ASSY. HYD .375 X 26 FL
15 CUSHION CYL RUBBER 35 HOSE ASSY. HYD .375 X 90 FL
16 SPACER 33MM ID X2''ODX22MM YZD 100 FASTENER TIE-WRAP .18 X 15.5LG BLK
NYL
17 PIN WINGLIFT
18 VALVE /A BALL
SDX30 Wing Lift Hydraulics - 2
nd
Serial Range
