SECTION 2 - MECHANICAL SERVICE
page 2-28
SDX30 MAIN FRAME CASTER ASSEMBLY
NOTE: The standard heavy duty 8 bolt hub is shown. This caster is used on all SDX30 machines from Serial No
CBJ0007001. The other 6 and 8 bolts hubs previously used on this machine are similar. Refer to your parts
book.
REF DESCRIPTION REF DESCRIPTION
1 BUSHING BRONZE 3 ID X 3.5 OD 18 AXLE BOGIE HVY 1.5" DROP LH
2 WASHER, THRUST 3.04 ID 4.0 OD .188 HRD 19 HUB ASSY. H811-8 C/W CUPS AND STUDS
(Includes cups, studs and nut)
3 RETAINER KING PIN PNT 20 SUPPORT TRUSS/W MAIN FRAME RH
4 TYRE/TIRE 31 X 13.5 - 15 10PR HF-1
(Purchase Locally)
20 SUPPORT TRUSS/W MAIN FRAME LH
5 RIM, WHEEL 15X10LB 8-HOLE 2.25 OFFSET 21 BEARING TAPER
6 TYRE/TIRE WTV 15X10 8H W/31 X13.5
10PR(Includes wheel, tire and valve stem)
22 BEARING, CONE #25877
7 WASHER SPACER 23 BEARING, CONE #25590
8 BUSHING TNSN 1.75 OD 1.5 ID 24 PIN, COTTER .188 X 1.5 YZD
9 NUT LOCK JAM 1.5-6 THIN YZD 25 WASHER 1.06ID 2.1 .25 YZD
10 NUT, LOCK .5 UNC GR A YZD NYL LK 26 NUT SLOTTED 1-14 UNS GR5 YZD
11 CASTER BOGIE PNT 27 SEAL HUB OIL <SE16>
12 AXLE HEAVY DUTY BOGIE RH (Order
Components)
28 CAP HUB DUST DC17 BLK
12 AXLE HEAVY DUTY BOGIE LH (Order
Components)
29 NIPPLE, LUBE GREASE ZERK STR .25NF
TAPER
13 BOLT .5 X 5 UNC GR5 YZD 30 HUB CAST/8
14 BOLT .75 X 1 UNC GR5 YZD 31 STUD .563 UNF GR5 WB41
15 PIN, PIVOT 1.5OD X 5.630UL YZD 32 BEARING, CUP #25520
16 WASHER, LOCK .75 YZD 33 BEARING, CUP #13621
17 BEARING, CONE W/SEAL 34 BEARING, CUP #25821
18 AXLE BOGIE HVY 1.5" DROP RH 100 VALVE TIRE STEM
Caster Assembly Parts
To Next Page
