SECTION 1 - SAFETY
page 1-14
SDX30 2
nd
SERIAL RANGE - starting at Serial Number CBJ0007001
REF DESCRIPTION REF DESCRIPTION
1 NUT .5 UNC GR2 YZD 17 REFLECTOR RED
2 WASHER, LOCK .5 YZD 18 REFLECTOR AMBER
3 LIGHT ASSY. TAIL/SIGNAL RED 19 REFLECTOR ORANGE
4 CONSOLE IMPLEMENT LIGHTNG
CONTROL
20 BRACKET SDX TRANSPORT LIGHT PTD
5 HARNESS LTG SDTOOL CONCORD 31' 21 BRACKET A/TRANSPORT
6 PLATE, LARGE BACKUP 22 BRACKET SOCKET SMV SIGN / LAMP
MOUNT
7 RIVET 1/4 X .500 23 NUT .5 UNF GR5 YZD
8 NUT, LOCK 1 UNC GR B YZD 24 BRACE /W BOLTING SDX-30 MAIN
9 NUT, LOCK .5 UNC GR A YZD NYL LK 25 BOLT .375 X 1 UNC GR5 YZD
10 NUT, LOCK .75 UNC GR C YZD 26 BOLT .5 X 7.5 UNC GR5 YZD
11 NUT .313 UNC YZD NYL INS 27 BOLT .75 X 2.5 UNC GR5 YZD
12 CONNECTOR CAB PLSTC RCP 2C 28 BOLT 1-8 X 2.50 GRADE 8 Z
13 DECAL SMV EMBLEM 29 BOLT 5/16-18 X3/4 GR5 ZND CRG
14 TRAFFIC SIGNS PLATE - SMV 30 WASHER, LOCK .5 YZD
15 SUPPORT SMV SIGN 31 WASHER .25 SAE YZD
16 PLATE ASSY. SMV 32 WASHER .406 ID .812 .065 YZD
EMBLEM PLATE ASSY, SMV 2 BOLT
HOLES
33 WASHER .531 X 1.062 X .095
SCREW MCH .25-20X.5 PH PI YZD 34 WASHER .813 ID 1.5 YZD SAE
NUT .25 UNC GR5 YZD 36 LIGHT ASSY. WARNING
Drill Transport Lights, Reflector Decals, and SMV Sign
