SECTION 2 - MECHANICAL SERVICE
page 2-34
SDX40 MAIN FRAME REAR BOGIE WHEEL SERVICE
NOTE: The main frame bogies are shown. For information on repacking the 812 hubs, refer to the SDX40 Caster
Section.
REF DESCRIPTION REF DESCRIPTION
1 BOLT STUD .625 UNF GR5 WB46 19 WASHER 1.531 ID X 2.125 8GA BLK
2 NUT WHEEL .625-18UNF GR B YZD 20 BEARING, CUP #13621
3 NUT LOCK .75 UNC GR B YZD 21 TYRE/TIRE 31 X 13.5 - 15 10PR HF-1
4 WTV 31X13.5 -15 14PR 8-HOLES 22 CHART RIM 15X10LBH 8H -1.5OFF
5 PLATE,SMALL SQUARE SHIM REAR BOGIE 23 TIRE VALVE STEM
6 MOUNTING REAR BOGIE 24 AXLE SPINDLE BOGIE 6100 LB
7 HUB H812-16 C/W CUPS & STUDS 25 PIN, COTTER .188 X 1.5 YZD
8 WASHER, LOCK .75 YZD REG 26 SLEEVE SPINDLE WEAR FOR S812
9 PIN, PIVOT 1.5OD X 5.630UL YZD 27 OIL-SEAL HUB (SE17)
10 WASHER .813 ID 1.5 YZD SAE 28 BEARING, CONE TM#3780
11 BEARING, CONE W/SEAL 29 BEARING, CUP #3720
12 PLATE, LOCKING YZD 30 BEARING, CUP #2720
13 BOLT .75 X 2.25 UNC GR5 YZD 31 BEARING, ROLLER CONE TM#2790
14 NUT LOCK JAM 1.5-6 THIN YZD 32 WASHER SPINDLE WA17 1.0 ID
15 AXLE BOGIE/W OFFSET RH (Shown) 33 NUT SLOTTED 1-14 UNS GR5 YZD
15 AXLE BOGIE/W OFFSET LH (Not Shown) 34 CAP HUB DUST DC17 PLN
16 BOLT .5 X 5 UNC GR5 YZD 35 SPINDLE AND HUB ASSY BOLT - IN 6100 LB
17 BOLT .75 X 2.75 UNC GR8 YZD 36 NIPPLE, LUBE GREASE ZERK STR .25NF
TAPER
18 NUT, LOCK .5 UNC GR A YZD NYL LK 37 BUSHING TNSN 1.75 X 1.5 X 1LG
Main Frame Bogie Assembly Parts
