SECTION 2 - MECHANICAL SERVICE
page 2-32
SDX40 WING FRAME FRONT CASTER ASSEMBLY
NOTE: The wing frame caster hubs are shown. For information on repacking the 811 hubs, refer to the SDX40 Bogie
Section.
REF DESCRIPTION REF DESCRIPTION
1 CASTER ASSY FRONT (Includes tension
bushings)
18 BEARING CUP #25520
2 BUSHING TNSN 1.75 X 1.5 X 1LG 19 BEARING CONE #25590
3 PIN, PIVOT 1.5OD X 5.630UL YZD 20 PIN, COTTER .188 X 1.5 YZD
4 WASHER .813 ID 1.5 YZD SAE 21 WASHER 1.531 ID X 2.125 8GA BLK
5 WASHER, LOCK .75 YZD REG 22 BEARING, CONE W/SEAL
6 BOLT .5 X 5 UNC GR5 YZD 23 BEARING, CUP #13621
7 AXLE SPINDLE BOGIE 5050 LB 24 NUT, LOCK .5 UNC GR A YZD NYL LK
8 OIL-SEAL HUB (SE16) 25 AXLE BOGIE/W OFFSET RH (Shown)
9 STUD .563 UNF GR5 WB41 26 AXLE BOGIE/W OFFSET LH (Not Shown)
10 HUB H811-8 C/W CUPS AND STUDS 26 NUT LOCK JAM 1.5-6 THIN YZD
11 NUT WHEEL .563 UNF CTD# WB40 27 BOLT .75 X 1.5 UNC GR5 YZD
12 BEARING CUP #25821 28 PLATE, LOCKING YZD
13 P.WASHER 1.06ID 2.1 .25 YZD 29 SPINDLE AND HUB ASSY BOLT - IN 5050
LB
14 NUT SLOTTED 1-14 UNS GR5 YZD 30 TIRE/A 15X10 8H W/31X13.5 10P
15 CAP HUB DUST DC17 PLN 31 TIRE 31 X 13.5 - 15 10PR HF-1
16 BEARING CONE #25877 32 CHART RIM 15X10LBH 8H+2.25OFF
17 GREASE ZERK STR .25NF TAPER 33 TIRE VALVE STEM
Wing Frame Caster Assembly Parts
