SECTION 3 - HYDRAULIC SYSTEM SERVICE
page 3-22
SDX40 WING LIFT HYDRAULICS
REF DESCRIPTION
1 FITTING PIO CPLR .5M-TIP .5FP
2 CYLINDER ASSY. HYD 5.00 X 30 IOWA
2 CYLINDER ASSY. HYD 5.00 X 30 MON
3 VALVE BALL
4 FITTING STL .5MP .5MJ BULKHD YZD
5 WASHER .438 ID 1.0 .083 YZD
6 FITTING STL 90DEG .5MB .5MJ
7 CROSS FIT STL .5MJ
8 ADAPTER TMK#2404-8-8
9 HANDLE VALVE (Includes 60-6267T1)
9 GRIP HANDLE VINYL 1 X 1.88 X3.88LG
10 BOLT .375 X 1 UNC GR5 YZD
11 ISOLATOR HOSE CLAMP SMALL
12 CLAMP HOSE FORMED 2.88X.94PNT
13 NUT, LOCK .312-18 SER FLNGE GR.5 ZND
14 TEE FIT STL .5MJ
15 BRACKET VALVE MOUNT PNT
16 FITTING STL .5MJ .5FJ RESTRICTOR
20 HOSE ASSY. HYD .375 X 215 FL
21 HOSE ASSY. HYD .375 X 200 FL
22 HOSE ASSY. HYD .375 X 26 FL
23 HOSE ASSY. HYD .375 X 90 FL
24 HOSE ASSY. HYD .375 X 168 FL
25 HOSE ASSY. HYD .375 X 135 FL
100 FASTENER TIE-WRAP .18 X 15.5LG BLK NYL
100 FITTING PIO CPLR .5M-TIP .5FP
SDX40 Wing Lift Hydraulic Circuit
