SECTION 2 - MECHANICAL SERVICE
page 2-5
GRADE 2* GRADE 5, 5.1, OR 5.2 GRADE 8 OR 8.2 L9 (ALLOY)
Dry ** Lubricated** Dry ** Lubricated** Dry ** Lubricated** Head Nut
SIZE
N
AmlbfAft NAmlbfAft NAmlbfAft NAmlbfAft NAmlbfAft NAmlbfAft NAmlbfAft NAmlbfAft
1/4 UNF 7.5 5.5 5.7 4.2 10.8 8 8.5 6.3 16.3 12 12.2 9 13.6 10 14.9 11
1/4 UNC 8.5 6.3 6.4 4.7 13.6 10 9.8 7.2 19 14 13.6 10 16.3 12 17.6 13
5/16 UNF 15 11 11 8 23 17 18 13 33 24 24 18 26 19 28 21
5/16 UNC 16 12 12 9 26 19 19 14 37 27 27 20 27 20 31 23
3/8 UNF 27 20 20 15 41 30 31 23 61 45 47 35 41 30 45 33
3/8 UNC 31 23 23 17 47 35 34 25 68 50 47 35 47 35 52 38
7/16 UNF 43 32 33 24 68 50 47 35 95 70 68 50 75 55 81 60
7/16 UNC 49 36 37 27 75 55 54 40 108 80 81 60 81 60 88 65
1/2 UNF 68 50 47 35 102 75 75 55 149 110 108 80 115 85 129 95
1/2 UNC 75 55 54 40 115 85 88 65 163 120 122 90 129 95 142 105
9/16 UNF 95 70 75 55 149 110 108 80 203 150 149 110 163 120 190 140
9/16 UNC 108 80 81 60 163 120 122 90 231 170 176 130 183 135 203 150
5/8 UNF 136 100 102 75 203 150 149 110 285 210 217 160 231 170 251 185
5/8 UNC 149 110 115 85 231 170 176 130 325 240 244 180 258 190 278 205
3/4 UNF 237 175 176 130 353 260 271 200 515 380 380 280 359 265 393 290
3/4 UNC 271 200 190 140 407 300 298 220 570 420 420 310 447 330 481 355
7/8 UNF 231 170 170 125 583 430 434 320 814 600 610 450 644 475 685 505
7/8 UNC 244 180 190 140 637 470 475 350 909 670 678 500 705 520 793 585
1 UNF 339 250 258 190 868 640 651 480 1234 910 922 680 746 550 1051 775
1 UNC 380 280 285 210 976 720 732 540 1383 1020 1031 760 949 700 1220 900
1-1/8 UNF 475 350 366 270 1071 790 800 590 1749 1290 1315 970 1390 1025 1559 1150
1-1/8 UNC 542 400 407 300 1207 890 909 670 1953 1440 1464 1080 1559 1150 1797 1325
1-1/4 UNF 678 500 515 380 1519 1120 1139 840 2468 1820 1844 1360 1898 1400 2170 1600
1-1/4 UNC 746 550 570 420 1681 1240 1261 930 2726 2010 2048 1510 2170 1600 2373 1750
1-1/2 UNF 1180 870 881 650 2644 1950 1980 1460 4285 3160 3214 2370 3932 2900 4407 3250
1-1/2 UNC 1329 980 990 730 2983 2200 2224 1640 4827 3560 3621 2670 4475 3300 4949 3650
Bolt Torque Information
DO NOT use these values if a different torque value or tightening procedure is given for a specific application. Torque values listed are for
general use only. Check tightness of fasteners periodically. Shear bolts are designed to fail under predetermined loads. Always replace shear
bolts with identical grade bolts.
** ‘Lubricated’ means coated with a lubricant such as engine oil, or fasteners with phosphate and oil coatings. ‘Dry’ means plain
or zinc plated without any lubrication.
* Grade 2 applies for hex caps (not hex bolts) up to 152 mm (6") long. Grade 1 applies for hex cap screws over 152 mm (6")
long, and for all other types of bolts and screws of any length.
