SECTION 7 - ENDMARKER SERVICE
page 7-12
ENDMARKER HYDRAULICS
REF DESCRIPTION REF DESCRIPTION
1 VALVE HYD SEQUENCE 2 WAY 12 BOLT .375 X 1 UNC GR5 YZD
2 FITTING PIO CPLR .5M-TIP .5FP 13 PLUG FIT STL .5MB HEX
3 VALVE, PRESSURE RELIEF 1000PSI 14 ISOLATOR HOSE CLAMP SMALL
4 FITTING STL .5MB .5MJ RES 0.0625 15 CLAMP HOSE FORMED 2.88X.94PNT
5 CYLINDER ASSY. 2.5" X 12" PNTD 16 BRACKET, SUPPORTING MOUNT
6 U-BOLT US .313 8.125W 7.00D 17 NUT, LOCK .313 UNC GR C YZD
7 WASHER .438 ID 1.0 .083 YZD 18 CONNECTOR FIT STL .5MB .375MJ ADTR
8 ELBOW FIT STL 90DEG .5MB .375MJ 19 FITTING, REDUCER 1/2 X 3/8
9 TEE FIT STL .375MJ .375MJ .5MB 21 HOSE ASSY. HYD .25 X 360 FL
10 VALVE BLOCK ALUMINUM PLN 22 HOSE ASSY. HYD .25 X 344 FL
11 BOLT .313 X 1.75 UNC GR5 YZD 23 HOSE ASSY. HYD .25 X 188 F7L
SDX40 Endmarker Hydraulics
