Case SDX30 - Page 171

INDEX
Reflector Decals, Slow Moving Vehicle Sign and
Transport Lighting.................1-13
SDX30 1
st
Serial Range ...............1-13
SDX30 2
nd
Serial Range ...............1-14
SDX40 ............................1-16
Transport Lighting Wiring Schematic.....1-18
Remote Clutch ..........................4-4
Remote Work Switch ....................4-5
Repacking Wheel Bearings ...............2-27
Repair Part Identification ....................i
SDX30 ...............................i
SDX40 .............................. ii
Replacing Serial/PIN Plate ................2-7
Safety.................................1-3
Air and Air Hoses .....................1-8
Electrical ............................1-9
General Safety Practices ...............1-4
Hydraulics and Hydraulic Leaks ..........1-8
Safety Decals .......................1-10
Safety During Operation................1-5
Safety During Transport ...............1-10
Servicing Safety Precautions ............1-4
Shields .............................1-9
Tires ...............................1-9
SDX30 Endmarker.......................7-4
Adjustments .........................7-7
Hydraulics...........................7-6
Offset Pin at Knuckle Pivot. .............7-7
SDX40 Endmarker......................7-10
Adjusting Disc Angle .................7-14
Bias Spring .........................7-15
Breakaway Adjustment................7-14
Hydraulics..........................7-12
Single Rank Operation....................6-6
ADX Air Delivery System...............6-6
Concord Air Delivery ..................6-6
Spindle Specifications ...................2-27
Storage...............................2-12
Torque Values for Tie Rods ................3-9
Troubleshooting Tables ...................5-3
Welding ..............................2-13
Wheel Bolt Torque ......................2-26
Wing Frame ..........................2-22
SDX30 ............................2-22
SDX40 ............................2-24
Wing Lift Ball Valve .....................3-18
