SECTION 3 - HYDRAULIC SYSTEM SERVICE
page 3-6
Seals, Washers, and O-Rings
645548
REF DESCRIPTION REF DESCRIPTION
CYLINDER ASSY. HYD 4 X 30 MONARCH
(SDX30)
5 CYLINDER TUBE
CYLINDER ASSY. HYD 5 X 30 MONARCH
(SDX40)
6 BOLT
1 HEAD 20 NUT, 5/8"
2 HEAD 25 NUT, LOCK, 1 1/8"
3 PISTON 27 PLUG, 3/4"
4 ROD
List of Seals, Washers, and O-Rings (3000 PSI)
