Case SDX30 - Page 87

SECTION 3 - HYDRAULIC SYSTEM SERVICE
page 3-26
SDX30 2
nd
SERIAL RANGE - Starting with Serial Number CBJ0007001
REF DESCRIPTION
1 FITTING STL .5MB .5MB
2 CLAMP HOSE FORMED 2.88X.94PNT
3 FITTING, REDUCER TUBE, REDUCER 1/2 X 3/8
4 TEE 1/2-37 DEG FL-SWIVEL RUN
5 FITTING STL 90DEG .5MB .5MJ
6 ELBOW 90DEG .5MB .375MJ
7 CONNECTOR FIT STL T .5MJ .5MJ .5MB
8 TEE .375MJ .375MJ .5MB
9 O-RING 1/2 OD TUBE CLASS 6
10 CYLINDER 4X12 CTD 3000PSI W/ 1 PIN (Includes pin 350108A1 and two clips 350109A1)
10 CYLINDER ASSY. 4X12 CTD 3000PSI W/ 1 PIN (No pins or clips)
11 ISOLATOR HOSE CLAMP SMALL
12 VALVE, CHECK BLOCK PILOT OPERATED
13 VALVE, PILOT CART HYD CHECK
14 BOLT .375 X 1 UNC GR5 YZD
15 WASHER .438 ID 1.0 .083 YZD
20 HOSE ASSY. HYD .375 X 190 FL
21 HOSE ASSY. HYD .375 X 189 FL
22 HOSE ASSY. HYD .375 X 168 FL
24 HOSE HYD .375 X 188
25 HOSE HYD .25 X 188 FL
26 HOSE HYD .375 X 100 FL
27 HOSE HYD .25 X 100 FL
100 FASTENER TIE-WRAP .18 X 15.5LG BLK NYL
SDX30 Subbar 2
nd
Serial Range - Part 1 of 2
