VLAN Management
Regular VLANs
267 Cisco 500 Series Stackable Managed Switch Administration Guide
14
The port mode for each port or LAG appears with its current port mode (Access,
Trunk, General, Private-Host, Private-Promiscuous or Customer) configured from
the Interface Settings page.
Each port or LAG appears with its current registration to the VLAN.
STEP 3 Change the registration of an interface to the VLAN by selecting its Interface
Name and selecting the desired option from the following list:
• VLAN Mode—Type of ports in the VLAN.
• Membership Type:
- Forbidden—The interface is not allowed to join the VLAN even from
GVRP registration. When a port is not a member of any other VLAN,
enabling this option on the port makes the port part of internal VLAN
4095 (a reserved VID).
- Excluded—The interface is currently not a member of the VLAN. This is
the default for all the ports and LAGs. The port can join the VLAN
through GVRP registration.
- Ta g g e d—The interface is a tagged member of the VLAN.
- Untagged—The interface is an untagged member of the VLAN. Frames
of the VLAN are sent untagged to the interface VLAN.
- PVID—Select to set the PVID of the interface to the VID of the VLAN.
PVID is a per-port setting.
STEP 4 Click Apply. The interfaces are assigned to the VLAN, and written to the Running
Configuration file.
You can continue to display and/or configure port membership of another VLAN
by selecting another VLAN ID.
Port VLAN Membership
The Port VLAN Membership page displays all ports on the device along with a list
of VLANs to which each port belongs.
If the port-based authentication method for an interface is 802.1x and the
Administrative Port Control is Auto, then:
