IP Configuration: RIPv2
Configuring RIP
415 Cisco 500 Series Stackable Managed Switch Administration Guide
19
Creating an Access List
To set the global configuration of an access list.
STEP 1 Click IP Configuration > IPv4 Management and Interfaces > Access List >
Access List Settings.
STEP 2 To add a new Access List, click Add to open the Add Access List page and enter
the following fields:
• Name—Define a name for the access list.
• Source IPv4 Address—Enter the source IPv4 address. The following
options are available:
- Any—All IP addresses are included.
- User Defined—Enter an IP address.
• Source IPv4 Mask—Enter the source IPv4 address mask type and value.
The following options are available:
- Network Mask—Enter the network mask.
- Prefix Length—Enter the prefix length.
• Action—Select an action for the access list. The following options are
available:
- Permit—Permit entry of packets from the IP address(es) in the access
list.
- Deny—Reject entry of packets from the IP address(es) in the access list.
STEP 3 Click Apply. The settings are written to the Running Configuration file.
Populate an Access List
To populate an access list with IP addresses.
STEP 1 Click IP Configuration > > IPv4 Management and Interfaces > Access List >
Source IPv4 Address List.
STEP 2 To modify the parameters of an access list, click Add to open the Edit Access List
page and modify any of the following fields:
• Access List Name—Name of the access list.
To Next Page
