Cisco ASR 9000 Series

SUMMARY STEPS
1. configure
2. l2vpn
3. xconnect group group-name
4. p2p xconnect-name
5. neighbor ip-address pw-id value
6. neighbor { A.B.C.D } { pw-id value }
7. Use the commit or end command.
DETAILED STEPS
Step 1 configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters the Global Configuration mode.
Step 2 l2vpn
Example:
RP/0/RSP0/CPU0:router(config)# l2vpn
RP/0/RSP0/CPU0:router(config-l2vpn)#
Enters L2VPN configuration mode.
Step 3 xconnect group group-name
Example:
RP/0/RSP0/CPU0:router(config-l2vpn)# xconnect group A
RP/0/RSP0/CPU0:router(config-l2vpn-xc)#
Enters the name of the cross-connect group.
Step 4 p2p xconnect-name
Example:
RP/0/RSP0/CPU0:router(config-l2vpn-xc)# p2p rtrX_to_rtrY
RP/0/RSP0/CPU0:router(config-l2vpn-xc-p2p)#
Enters a name for the point-to-point cross-connect.
Step 5 neighbor ip-address pw-id value
Example:
RP/0/RSP0/CPU0:router(config-l2vpn-xc-p2p)# neighbor 1.1.1.1 pw-id 2
RP/0/RSP0/CPU0:router(config-l2vpn-xc-p2p-pw)#
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
148
Implementing Point to Point Layer 2 Services
Configuring a Backup Pseudowire
