DETAILED STEPS
Step 1 l2vpn
Example:
RP/0/RSP0/CPU0:router(config)# l2vpn
Enters the l2vpn configuration mode.
Step 2 bridge group bridge-group-name
Example:
RP/0/RSP0/CPU0:router(config-l2vpn)# bridge group bridgegroup1
Enters the bridge group configuration mode.
Step 3 bridge-domain bridge-domain-name
Example:
RP/0/RSP0/CPU0:router(config-l2vpn-bg)# bridge-domain bdomain1
Enters the bridge domain configuration mode.
Step 4 member vni vxlan-identifier
Example:
RP/0/RSP0/CPU0:router(config-l2vpn-bg-bd)# member vni 100
Associates a VXLAN with the bridge domain.
Step 5 interface gigabitEthernet sub-interface-identifier
Example:
RP/0/RSP0/CPU0:router(config-l2vpn-bg-bd)# interface gigabitEthernet 0/0/0/0.200
Associates a VLAN with the bridge domain using the VLAN sub-interface.
Step 6 Use the commit or end command.
commit - Saves the configuration changes and remains within the configuration session.
end - Prompts user to take one of these actions:
• Yes - Saves configuration changes and exits the configuration session.
• No - Exits the configuration session without committing the configuration changes.
• Cancel - Remains in the configuration mode, without committing the configuration changes.
Configuring VXLAN source UDP port
This is an optional task. By default, the source UDP port of the encapsulating VXLAN segment is calculated
via hash functions on the layer 2 address fields of the inner payload. Perform this task to configure the hash
functions to be performed on either the layer 2 or the layer 3 address fields of the inner payload.
SUMMARY STEPS
1. l2vpn
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
480
Implementing VXLAN
Configuring VXLAN source UDP port
