• Cancel - Remains in the configuration mode, without committing the configuration changes.
Enabling L2TP Static Submode
Perform this task to enable L2TP static submode.
SUMMARY STEPS
1. configure
2. l2vpn
3. xconnect group group-name
4. p2p xconnect-name
5. interface type interface-path-id
6. neighbor ipv6 peer-address pw-id pseudowire-id
7. l2tp static
8. Use the commit or end command.
DETAILED STEPS
Step 1 configure
Example:
RP/0/RSP0/CPU0:router # configure
Enters the Global Configuration mode.
Step 2 l2vpn
Example:
RP/0/RSP0/CPU0:router (config)# l2vpn
Enters Layer 2 VPN configuration mode.
Step 3 xconnect group group-name
Example:
RP/0/RSP0/CPU0:router (config-l2vpn)# xconnect group g1
Configures the cross-connect group.
Step 4 p2p xconnect-name
Example:
RP/0/RSP0/CPU0:router (config-l2vpn-xc)# p2p xc3
Configures the point-to-point cross-connect.
Step 5 interface type interface-path-id
Example:
RP/0/RSP0/CPU0:router (config-l2vpn-xc-p2p)# interface GigabitEthernet0/0/0/4.2
Specifies the interface type ID.
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
160
Implementing Point to Point Layer 2 Services
Enabling L2TP Static Submode
