Cisco ASR 9000 Series Configuration Guidelines

ModificationRelease
Support was added for Multipoint Layer 2 Services
Label Switched Multicast feature.
Release 5.1.0
Support was added for:
• Pseudowire Headend PW-Ether sub-interfaces
(VC Type 5) and Pseudowire Headend PW-IW
interworking interfaces (VC Type 11)
• LFA over Pseudowire Headend.
Release 5.1.1
Support was added for:
• Service Path Preference for L2VPN
• L2VPN Route Policy
Release 6.1.2
• Prerequisites for Implementing Multipoint Layer 2 Services, on page 203
• Information About Implementing Multipoint Layer 2 Services , on page 203
• How to Implement Multipoint Layer 2 Services, on page 229
• Configuration Examples for Multipoint Layer 2 Services, on page 321
Prerequisites for Implementing Multipoint Layer 2 Services
Before configuring Multipoint Layer 2 Services, ensure that these tasks and conditions are met:
• You must be in a user group associated with a task group that includes the proper task IDs. The command
reference guides include the task IDs required for each command.
If you suspect user group assignment is preventing you from using a command, contact your AAA
administrator for assistance.
• Configure IP routing in the core so that the provider edge (PE) routers can reach each other through IP.
• Configure a loopback interface to originate and terminate Layer 2 traffic. Make sure that the PE routers
can access the other router's loopback interface.
The loopback interface is not needed in all cases. For example, tunnel selection
does not need a loopback interface when Multipoint Layer 2 Services are directly
mapped to a TE tunnel.
Note
• Configure MPLS and Label Distribution Protocol (LDP) in the core so that a label switched path (LSP)
exists between the PE routers.
Information About Implementing Multipoint Layer 2 Services
To implement Multipoint Layer 2 Services, you should understand these concepts:
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
203
Implementing Multipoint Layer 2 Services
Prerequisites for Implementing Multipoint Layer 2 Services

Cisco ASR 9000 Series Specifications

General

Series	ASR 9000
Category	Network Router
Modular Design	Yes
Redundancy	Yes (Hardware and Software)
Operating System	Cisco IOS XR
Interfaces/Ports	10G, 40G, 100G, 400G Ethernet
Expansion Slots	Varies by model
Routing Protocol	BGP, OSPF, IS-IS, EIGRP
Management	CLI, SNMP, NETCONF
Power Supply	Redundant
Port Density	Varies by model
Power Supply Options	AC, DC
Memory	Varies by model
Storage	Varies by model
Dimensions	Varies by model
Weight	Varies by model
