Example:

RP/0/RSP0/CPU0:router(config-l2vpn)# xconnect group L2TPV3_V4_XC_GRP

Enter a name for the cross-connect group.

Step 4 p2p name

Example:

RP/0/RSP0/CPU0:router(config-l2vpn-xc)# p2p L2TPV3_P2P_1

Enters p2p configuration submode to configure point-to-point cross-connects.

Step 5 interface type interface-path-id

Example:

RP/0/RSP0/CPU0:router(config-l2vpn-xc-p2p)# interface GigabitEthernet 0/2/0/0/0.1

Specifies the interface type ID. The choices are:

• GigabitEthernet

• TenGigE

Step 6 neighbor ipv4 ip-address pw-id number

Example:

RP/0/RSP0/CPU0:router(config-l2vpn-xc-p2p)# neighbor ipv4 26.26.26.26 pw-id 100

Configures a pseudowire for a cross-connect.

Step 7 pw-class pw-class-name

Example:

RP/0/RSP0/CPU0:router(config-l2vpn-xc-p2p-pw)# pw-class L2TPV3_V4_CLASS

Enters pseudowire class submode to define a name for the cross-connect.

Step 8 Use the commit or end command.

commit - Saves the configuration changes and remains within the configuration session.

end - Prompts user to take one of these actions:

• Yes - Saves configuration changes and exits the configuration session.

• No - Exits the configuration session without committing the configuration changes.

• Cancel - Remains in the configuration mode, without committing the configuration changes.

Configuring L2TPv3 Encapsulation and Protocol: Example

This example shows how to set the encapsulation and protocol for L2TPv3 tunnels:

configure

l2vpn

L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x

198

Implementing Point to Point Layer 2 Services

Configuring L2TPv3 Encapsulation and Protocol: Example
