Example:
RP/0/RSP0/CPU0:router(config-evpn-evi-bgp)# exit
Exits the current configuration mode.
Step 9 advertise-mac
Example:
RP/0/RSP0/CPU0:router(config-evpn-evi)# advertise-mac
Advertises the MAC route.
Step 10 Use the commit or end command.
commit - Saves the configuration changes and remains within the configuration session.
end - Prompts user to take one of these actions:
• Yes - Saves configuration changes and exits the configuration session.
• No - Exits the configuration session without committing the configuration changes.
• Cancel - Remains in the configuration mode, without committing the configuration changes.
Configure Layer 2 Interface
Perform this task to define Layer 2 interface.
SUMMARY STEPS
1. configure
2. interface bundle-ether instance.subinterface l2transport
3. (Optional) no shut
4. encapsulation dot1q vlan-id
5. (Optional) rewrite tag pop dot1q vlan-id symmetric
6. Use the commit or end command.
DETAILED STEPS
Step 1 configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters the global configuration mode.
Step 2 interface bundle-ether instance.subinterface l2transport
Example:
RP/0/RSP0/CPU0:router(config)# interface bundle-ether2.1 l2transport
Configures the bundle ethernet interface and enables Layer 2 transport mode on the bundle ethernet interface.
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
538
EVPN Features
Configure Layer 2 Interface
