Cisco ASR 9000 Series Configuration Guidelines

Table 9: EVPN Attributes and Operators
Attribute-SetMatchAttributeAttach Point
—indestinationneighbor-in
—inrd
—isevpn-route-type
Yesinesi
Yesinetag
Yesinmac
—inevpn-originator
—inevpn-gateway
—
indestinationneighbor-out
—inrd
—isevpn-route-type
Yesinesi
Yesinetag
Yesinmac
—inevpn-originator
—inevpn-gateway
Configure EVPN RPL Feature
The following section describe how to configure mac-set, esi-set, evpn-gateway, and evpn-originator.
/* Configuring a mac-set and refering it in a route-policy (Attach point - neighbor-in) */
Router# configure
Router(config)# mac-set demo_mac_set
Router(config-mac)# 1234.ffff.aaa3,
Router(config-mac)# 2323.4444.ffff
Router(config-mac)# end-set
Router(config)# !
Router(config)# route-policy policy_use_pass_mac_set
Router(config-rpl)# if mac in demo_mac_set then
Router(config-rpl-if)# set med 200
Router(config-rpl-if)# else
Router(config-rpl-else)# set med 1000
Router(config-rpl-else)# endif
Router(config-rpl)# end-policy
Router(config)# commit
Router(config)# router bgp 100
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
576
EVPN Features
Configure EVPN RPL Feature
