0—Specifies that a plain-text secret is entered.•
• 7—Specifies that an encrypted secret is entered.
• password—Defines the shared secret between peer routers. The value entered for the password argument must be
in the format that matches the input format specified by the {0 | 7} keyword option.
• hash { MD5 | SHA1}—Specifies the hash function to be used in per-message digest calculations.
• MD5—Specifies HMAC-MD5 hashing (default value).
• SHA1—Specifies HMAC-SHA-1 hashing.
Step 8 hidden
Example:
RP/0/RSP0/CPU0:router(config-l2tp-class)# hidden
Enables AVP hiding when sending control messages to an L2TPv3 peer.
Configuring L2VPN Single Segment Pseudowire
To configure single segment pseudowire in the network, do the following:
1. (Optional) Configuring the related L2VPN Global Parameters. See Configuring L2VPN Global Parameters
This procedure is used to overwrite the default BGP Route Distinguisher (RD) auto-generated value and
also the Autonomous System Number (ASN) and Route Identifier (RID) of BGP.
2. Configuring L2VPN VPWS SS-PW
3. Configuring L2VPN MS-PW Address Family Under BGP
The address family is configured under BGP to exchange the dynamic pseudowire routes.
Configuring L2VPN Global Parameters
Perform this task to configure L2VPN global parameters.
SUMMARY STEPS
1. configure
2. l2vpn
3. router-id router-id
4. pw-routing
5. global-id global-id
6. bgp
7. rd route-distinguisher
8. Use the commit or end command.
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
172
Implementing Point to Point Layer 2 Services
Configuring L2VPN Single Segment Pseudowire
