RP/0/RSP0/CPU0:router(config-l2vpn-bg-bd)# interface GigabitEthernet0/5/0/0.20
Assigns the matching VLAN ID and Ethertype to the interface.
Step 6 pbb edge i-sid service-id core-bridge core-bridge-name
Example:
RP/0/RSP0/CPU0:router(config-l2vpn-bg-bd)# pbb edge i-sid 1000 core-bridge pbb-core
Configures the bridge domain as PBB edge with the service identifier and the assigned core bridge domain and enters
the PBB edge configuration submode.
This command also creates the Virtual instance port (VIP) that associates the PBB Edge bridge domain to the specified
Core bridge domain.
All the interfaces (bridge ports) under this bridge domain are treated as the customer network ports (CNP).
Step 7 unknown-unicast-bmac mac-address
Example:
RP/0/RSP0/CPU0:router(config-l2vpn-bg-bd-pbb-edge)# unknown-unicast-bmac 1.1.1
Configures unknown unicast backbone MAC address.
On Trident line cards, once you configure the unknown unicast BMAC, the BMAC is used to forward customer
traffic with multicast, broadcast and unknown unicast destination MAC address.
Note
Step 8 Use the commit or end command.
commit - Saves the configuration changes and remains within the configuration session.
end - Prompts user to take one of these actions:
• Yes - Saves configuration changes and exits the configuration session.
• No - Exits the configuration session without committing the configuration changes.
• Cancel - Remains in the configuration mode, without committing the configuration changes.
Configuring Static MAC addresses under PBB Edge Bridge Domain
Perform this task to configure the static MAC addresses under the PBB edge bridge domain.
SUMMARY STEPS
1. configure
2. l2vpn
3. bridge group bridge-group-name
4. bridge-domain domain-name
5. interface type interface-path-id.subinterface
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
380
Implementing IEEE 802.1ah Provider Backbone Bridge
Configuring Static MAC addresses under PBB Edge Bridge Domain
