Cisco ASR 9000 Series

SUMMARY STEPS
1. configure
2. l2vpn
3. bridge group bridge group name
4. bridge-domain bridge-domain name
5. vfi {vfi-name}
6. Use the commit or end command.
DETAILED STEPS
Step 1 configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters the Global Configuration mode.
Step 2 l2vpn
Example:
RP/0/RSP0/CPU0:router(config)# l2vpn
RP/0/RSP0/CPU0:router(config-l2vpn)#
Enters L2VPN configuration mode.
Step 3 bridge group bridge group name
Example:
RP/0/RSP0/CPU0:router(config-l2vpn)# bridge group csco
RP/0/RSP0/CPU0:router(config-l2vpn-bg)#
Creates a bridge group so that it can contain bridge domains and then assigns network interfaces to the bridge domain.
Step 4 bridge-domain bridge-domain name
Example:
RP/0/RSP0/CPU0:router(config-l2vpn-bg)# bridge-domain abc
RP/0/RSP0/CPU0:router(config-l2vpn-bg-bd)#
Establishes a bridge domain and enters L2VPN bridge group bridge domain configuration mode.
Step 5 vfi {vfi-name}
Example:
RP/0/RSP0/CPU0:router(config-l2vpn-bg-bd)# vfi v1
RP/0/RSP0/CPU0:router(config-l2vpn-bg-bd-vfi)#
Configures virtual forwarding interface (VFI) parameters and enters L2VPN bridge group bridge domain VFI configuration
mode.
Step 6 Use the commit or end command.
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
243
Implementing Multipoint Layer 2 Services
Creating the Virtual Forwarding Instance
