Cisco D9854 Installation And Configuration Guide

Setup Menu
135
TS Out - Options
To view the Options menu from the TS Out menu, press the RIGHT arrow key four
times.
The Options menu allows you to configure auto synchronization and fixed output
options for the MPEPoIP and ASI outputs.
The Options menu has the following structure:
Menu Item
Description
Parameters
Output
Select 1 to configure the ASI
output or select 2 to configure
the MPEG over IP output.
1 or 2
Fixed Output
Sets whether the DPM assigns
new values for all the output
channels and PIDs according to
the options below when you
Resynchronize All.
Yes or No

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
