Cisco D9854 Installation And Configuration Guide

Chapter 5 Web GUI Setup and Monitoring
256
Duplic Mode
Description
PSI Remap
Every input PID can be mapped to one output PID. If PID
mapping conflicts exist, DPM will use the Precedence Rule to
decide which output PID to use. All PMTs using the input PID
will be updated to reference the output PID specified by the
winner.
Pkt Copy
An input PID can be mapped to multiple output PIDs. The PID
will be duplicated as many times as needed (up to a certain
hardware limitation).
Pkt Copy is recommended for most applications.
4 From the Unreferenced Content drop-down list, choose the action to use for
unreferenced content. Unreferenced content is the remainder of the transport
that is not filtered by the program entries. Choose Drop (default) to drop all
unreferenced content. Choose Pass to pass all unreferenced content to the output
unchanged.
5 From the Service ID Output drop-down list, choose whether the receiver should
always generate PSI tables for the Mapped PE even if the selected input channel
is not available, or for only valid service channels/IDs. The following table
describes each service ID:
Svc ID
Description
Valid Ch
Only transmits the PSI tables for the mapped program if the
program exists on the input stream.
All Ch
Transmits the PSI tables for the mapped program even if the
program does not exist in the input stream.
All Ch is only valid if the PAT, NIT, SDT and PMT are set to
Regenerate.
6 From the SI Regeneration Option drop-down list, choose the SI regeneration
option that applies to the PowerVu rates (consistent with the uplink). This
parameter is only used if Remapping Mode is set to None. The following table
describes each PSI rate:
PSI Rate
Description
Auto
Matches the generated PSI tables' output rate as the incoming rate.
MPEG Min
Transmits the generated PSI tables on the longest intervals that are
allowed by MPEG standard.
SA Std
Transmits the generated PSI tables based on PowerVu standard
intervals.
7 From the PSI Table Output Option drop-down list, choose the output option
that allows the operator to specify which PSI tables to include in the
program/output stream. The following table describes each option:

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
