Configuring Transport Stream Information
Transmits the incoming PSI Tables as is; does not modify the
content and rate.
Does not transmit any PSI Tables.
The operator can click Table Options to select the output mode for
each table. The default table selections will be all pass, and only
with CDT dropped.
8 From the PSI Regeneration Option drop-down list, choose whether to
regenerate the PSI tables. You can select Always or As Needed (only if the
content has changed).
9 If Ctl By Table is selected as the PSI Table Output Option, click Table Options
to configure the DPM table options. The DPM Table Options (MOIP) window is
displayed.
10 Choose the tables which will be passed, dropped, regenerated or passed with
rate control (PwRC) from the MPEGoIP Output. For more information on the
table options, see PSI Table Settings (on page 131).
The CDT is different from the other tables listed because the CDT is referred to
within the PMT, rather than outside the PMT. Check the Block CDT Output
check box to override the DPM PID map configuration for CDT PIDs and to
always drop all CDTs. Otherwise, uncheck the Block CDT Output check box to
permit the output of CDTs following the configured DPM PID map
configuration and all other DPM constraints.
11 Click OK.
