Cisco D9865 Installation And Configuration Guide

4-24
Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Chapter 4 Setup and Monitoring via On-Screen Display
Setup Menu
Step 6 Press the blue button (Do Action) to save and apply the settings to the receiver until the next reboot.
Step 7 The following table describes the view-only information on the Dish Setup screen:
DiSEqC Enable Enables or disables Digital Satellite Equipment
Satellite Control, level 1.2.
Note This must be enabled to control the
DiSEqC switch. LNB Power must be on to
use this setting. Refer to
http://www.eutelsat.com/satellites/4_5_5.
html for more information.
Before you can adjust the satellite position using
the Adjust Dish Position screen or a signal tone,
ensure that the LNB Power and DiSEqC (in the
Tuning/Preset screen) are enabled.
Disable
Parameter Description
Modulation Indicates the modulation type for the received signal.
LDPC BER Indicates the bit rate of the input stream of the LDPC error
correcting stage (DVB-S2 only).
Mode Indicates whether the current dish setup mode is Installer or User.
The mode can be changed by pressing the yellow button.
NW Name Displays the network name.
PV BER Indicates the PV (Post-Viterbi) BER for the received signal
(DVB-S).
PER Indicates the current PER (Packet Error Rate).
DiSEqC Status Indicates whether the DiSEqC is enabled or disabled.
Signal Quality Indicates the quality of the received signal, associated with the Bit
Error Rate, in the range from 0 to 100.
Signal Level Displays the relative strength of the received RF input signal. It is
displayed in the range from 0 to 100.
Signal Lock Indicates whether the receiver is synchronized with the received RF
signal.
Selection Options Description
