show policy-map
Table 2-18 describes the fields in the show policy-map interface display. The fields in the table are
grouped according to the relevant QoS feature.
Related Commands
Table 3-14 show policy-map interface Field Descriptions
Field Description
Fields associated with classes or service policies
Service-policy input/output Name of the input or output service policy applied to the specified interface.
Class-map Class of traffic shown. Output appears for each configured class in the policy. The choice
for implementing class matches (match-all or match-any) might also appear next to the
traffic class.
packets Number of packets identified as belonging to the traffic class.
Match Match criteria specified for the class of traffic. This includes criteria such as class of service
(CoS) value, discard class, IP precedence value, multiprotocol label switching (MPLS)
experimental (EXP) value, Differentiated Services Code Point (DSCP) value, access groups,
and QoS groups.
Fields associated with policing
police Shown when the police command has been configured to enable traffic policing. Displays
the specified committed information rate (CIR) and conform burst size (BC) used for
policing packets.
conform-action Displays the action to be taken on packets marked as conforming to a specified rate.
conform Displays the number of packets marked as conforming to the specified rate.
exceed-action Displays the actions to be taken on packets marked as exceeding a specified rate.
exceed Displays the number of packets marked as exceeding the specified rate.
violate-action Displays the actions to be taken on packets marked as exceeding the maximum rate.
violate Displays the number of packets marked as exceeding the maximum rate.
Fields associated with queuing
Queue Limit Queue size configured for the class in number of packets.
Output Queue The queue created for this class of traffic.
Tail packets dropped The number of packets dropped when the mean queue depth is greater than the maximum
threshold value.
Fields associated with traffic scheduling
Traffic shaping The rate used for shaping traffic.
Bandwidth Bandwidth configured for this class in kbps or a percentage.
Priority Indicates that this class is configured for priority queuing.
Command Description
policy-map Creates or modifies a policy map that can be attached to multiple ports to
specify a service policy.
