2201R Mobile Tester SCPI Reference Guide
Chapter 2 Remote control of the 2201R Mobile Tester
47090/323
Copyright © 2016 Aeroflex Limited. All rights reserved.
30
The base station and mobile station parameter subsystems
These subsystems allow access to the base station (BS) parameters (i.e. the 2201R simulating a base station) and to
the information received from the mobile under test like the measurement report. The commands of these
subsystems are described here.
CONFigure – This subsystem incorporates all changeable BS parameters of all implemented communication systems.
CALL – This subsystem handles call procedures and allows to read out the measurement report generated by the
mobile under test.
The information available is dependent on the current state of a call, i.e. some commands require an established radio
communication link between the 2201R and the mobile under test.
The CONFigure subsystem
This subsystem incorporates all changeable BS parameters of all systems implemented. The key commands are the
following:
The CALL subsystem
This subsystem contains commands
• for call setup and handling procedures and
• to read out the measurement report, generated by the mobile.
NOTE
The settings made here directly affect all communication system-specific subsystems.
CONFigure:CSYStem
Selects the communications system to work with.
CONFigure:<SystemOption>:...
These commands select parameters within a communications
system.
CONFigure:<SystemOption>:BS:...
or
CONFigure:<SystemOption>:NB:...
These are the commands to set specific system parameters
like the base station's RF output power level or its identity.
CONFigure:<SystemOption> :MSTAtion:..
or
.CONFigure:<SystemOption> :UE:...
The mobile-specific information is handed over to the 2201R
using these commands. One example is the power level.
CONFigure:<SystemOption> :BER:...
These commands set the BER parameters.
CONFigure:<SystemOption> :GROup:...
With the help of these commands, groups of measurements
may be defined.
CONFigure:COUPloss:...
These commands provide access to the coupling loss
compensation feature of the 2201R.
