2201R Mobile Tester SCPI Reference Guide
Chapter 4 Common commands
47090/323
Copyright © 2016 Aeroflex Limited. All rights reserved.
49
The event status register
The event status register contains eight bits. The meaning of these bits is outlined in the table below.
The commands working on the event status register are described below the table.
Bit Decimal Meaning
7 128 Power on – this bit is always set.
664Not used.
5 32 Command error – this bit indicates that one of the SCPI
command errors occurred.
4 16 Execution error – is set after a SCPI execution error did occur.
3 8 Device-dependent error – this bit indicates that a device-specific
SCPI error did occur.
2 4 Query error – is set after a SCPI query error occurred.
1 2 Request control – this bit is reserved for future use.
0 1 Operation complete flag – is set as soon as the execution of a
command has been completed.
