2201R Mobile Tester SCPI Reference Guide
Chapter 2 Remote control of the 2201R Mobile Tester
47090/323
Copyright © 2016 Aeroflex Limited. All rights reserved.
29
Measuring operation register group
This group of registers is 16 bits wide. Its main task is to deal with events related to the measurement status.
The Result bit of this group of registers is forwarded to bit 9 of the general operation register group.
The FORMat subsystem – overview
The FORMat subsystem sets and queries settings concerning the data output in remote mode.
532Not used.
6 64 Not used.
7 128 Not used.
8 256 Not used.
9 512 Not used.
10 1024 Not used.
11 2048 Not used.
12 4096 Not used.
13 8192 Not used.
14 16384 Not used.
15 32768 Not used.
Bit Decimal Meaning
0 1 Set while RFTX measurements are in progress.
1 2 Set while RFRX measurements are in progress.
2 4 Set while RFSPectrum measurements are in progress.
38Not used.
4 16 Not used.
532Not used.
6 64 Set while UE Report or MS Info measurements are in progress.
7 128 Not used.
8 256 Not used.
9 512 Not used.
10 1024 Not used.
11 2048 Not used.
12 4096 Not used.
13 8192 Not used.
14 16384 Not used.
15 32768 Not used.
