DS8110 REFERENCE MANUAL
116
4
Field Name
Action/Definition
Server
Address
Enter the IP address of the server to which the client tries to connect. This parameter is
available only when the socket is configured as a Client.
Protocol
Select TCP (Transmission Control Protocol) or UDP (User Datagram Protocol) from the
drop-down list to define the protocol to be used for the Ethernet communication.
NOTE: When using the UDP protocol:
 The User Socket Client Port is bound to the Server Port.
 The maximum size for maintaining a whole datagram is 1436
bytes, messages exceeding this value will be fragmented.
Port
Enter the port number of the socket.
Fixed UDP
Destination
Port
When using UDP Server, select the check box to enable a fixed UDP destination port.
UDP
Destination
Port
When using UDP Server with a fixed UDP destination port, enter the port number.
Fixed UDP
Source Port
When using UDP Client, select the check box to enable a fixed UDP source port.
UDP Source
Port
When using UDP Client with a fixed UDP source port, enter the port number.
3. When you have finished making changes, click Update All to save all pending changes,
click Reset All to revert to all previously saved values, and click Reset Page to revert to
previous saved values on the current page.
