Discard Read
on Missing
Index
Select the check box to enable. When selected, if a Missed Index error
occurs, an empty telegram is sent to the Crisplant Host.
If not selected, and a Missed Index error occurs, the telegram contains the
codes that were read relative to the pack.
Select Trigger (Input 1) or Aux (Input 3) from the drop-down list. The
selection defines which digital input transmits information about the
conveyor direction. The conveyor direction is Forward when the selected
input is active (default active closed). If Input 1 is used the scanner Phase
On LED also signals the direction state.
SW Divide
Encoder
Frequency
Select the check box to enable. If selected, the encoder frequency value is
divided by two before it is transmitted to the Host. This parameter only
effects the value contained in the <Encoder> field of the messages sent
from the scanner to the Host.
Enter a message header in the field provided. A Header (up
to 128 bytes) can be defined and transmitted as a block
preceding all messages sent from the scanner. Character
from NUL (00H) to ~ (7EH) can be used.
Enter a message trailer in the field provided. A Trailer (up to
128 bytes) can be defined and transmitted as a block
following all messages sent from the scanner.
Character from NUL (00H) to ~ (7EH) can be used.
Select the check box to enable heartbeat.
Enter a value in milliseconds. This parameter is available
when the Heartbeat parameter is enabled. It defines the
amount of time between two message transmissions. If the
selected timeout expires and no transmission has occurred,
the Heartbeat message
will be transmitted.
Click to activate the Text Entry Tool and create a
heartbeat message in the field provided. This parameter is
available only when the Heartbeat parameter is enabled.
This defines the Heartbeat message.
Click Submit to save your changes, or click Cancel to return
to previous.
