DS8110 REFERENCE MANUAL
130
4
Field Name
Action/Definition
AM/PM
Behavior
Select the check box to enable. If enabled, the Host is ready
to receive the following message:
<STX><COMMAND><ETX>
where:
<COMMAND> = 'A' indicates that the Host starts working in
AM mode / 'P' indicates that the Host starts working in PM
(default) mode
When working in AM mode:
 each code is only filtered by the Encoder Timeout
parameter;
 the Purolator Custom Check parameter is not effective;
 the Heartbeat message will never be transmitted;
 the transmitted message is not subject to padding with
the Fill Character.
and the output message format is the following:
<STX><scanner_nr><space><barcode><ETX><CR><LF>
where:
<scanner_nr> = 2-digit number in the range 00-31
AM Message
Target
Select Main Serial Port, Aux Serial Port, or a User Socket
from the drop-down list.
Multi-Tx
Transport
Disable
This parameter manages the message transmission through
the different communication channels.
If unchecked (check box not selected), messages are
transmitted through all the communication channels having
the Data Tx parameter enabled.
If checked (check box selected), messages are sent through
all the communication channels having the Data Tx
parameter enabled until the scanner receives one of the
three possible communication messages (Status Request,
Encoder Counter Request, Initialization Command). As soon
as this condition occurs, all messages will be transmitted
only through the specific channel sending one of the three
possible communication messages while other channels are
ignored. In this way, the last channel sending one of the
possible communication messages will become the one used
for transmission.
