DS8110 REFERENCE MANUAL
216
5
9. Measure the distance for Z from the conveyor bed to the center of the barcode (top of
box), and enter that distance in the first box under Z-Coord (mm).
Your measurements will likely differ from those shown below.
10. Click Calibrate 2. PackTrack data is displayed for the second code.
11. Finally, place a system barcode on the back right edge of a box, about halfway up the
scanner field of view as shown in the illustration below.
50
50
