Datalogic DS8110 User Manual

TROUBLESHOOTING
257
7
Error
Code
Description
Severity
Explanation
Symptom
Troubleshooting
Action required
135
Encoder
Failure
Error
Phase input
(trigger source) is
activated while
encoder
(tachometer) is
stopped (PackTrack
Mode).
- No data will be
transmitted to
the host.
- Scanner(s) will
not read any
barcodes.
- System receives
trigger cycle
when no
encoder signal
is present.
- Check
Diagnostics |
Monitor to see
if the scanner is
reporting a
conveyor speed
(See section
4.7.1).
- Make sure the
encoder
(tachometer)
wheel is making
a firm contact
with the
conveyor.
- Adjust, realign,
or replace the
encoder
(tachometer).
157
SD Card
Failure
Error
SC5000 - SD card
cannot be
accessed. The SD
card contains the
backup files. It also
contains a copy of
the scanners
application
software.
This failure is only
in the SC5000.
- Unit will not
backup or
restore the
parameters.
Try to save the
parameters from
the SC5000 to the
SD card (see
SC5000 System
Controller
Reference
Manual).
- Confirm that the
SD card is
seated properly
in the SC5000.
- Replace SD card
(see SC5000
System
Controller
Reference
Manual).
169
Main Serial
Port Error
Error
Protocol Index
message not
received on Main
Serial Port.
176
Aux Serial
Port Error
Error
Protocol Index
message not
received on Aux
Serial Port.
178
Ethernet
Socket 1
Error
Error
Protocol Index
message not
received on User
Socket 1.
179
Ethernet
Socket 2
Error
Error
Protocol Index
message not
received on User
Socket 2.
180
Ethernet
Socket 3
Error
Error
Protocol Index
message not
received on User
Socket 3.
181
Ethernet
Socket 4
Error
Error
Protocol Index
message not
received on User
Socket 4.
