General View
xvi Matrix 300N
Matrix 300N™ 2 MP
Software Adjustable Focus (Liquid Lens) Models
Connector block
rotates to 90° position
Figure C















Device Class and Warning Labels
Power - Serial Interfaces - I/O
Co
nnector
Bracket Mounting Holes (4) Ethernet Connector
Good Read LED (green) No Read LED (red)
Lens Cover Aiming System Laser Pointers
HMI X-PRESS Interface Ethernet Connection LED
Lens Power On LED
Internal Illuminator
 
 
 
 
 
 

