Internal Network Configurations
Product Reference Guide 171
To view the connected Slave configurations:
1. Click on the Internal Network View tab at the bottom of the screen.
2. Open the Master branch by clicking on the arrow to the left of the Master
ic
on.
3. Select any slave. Wait for the configuration to load.
4. Click The Configuration tab at the bottom of the screen.
By selecting the various configuration steps above you can visualize the slave
co
nfiguration.
NOTE
You can modify some Slave Synchronized parameters from this view but you cannot
save them here.
To save changed slave parameters here, you must click on the Master and Save the
configuration overwriting it, making sure to select Save on Slave Device but without
Clone Master Configuration on Slaves, otherwise all
the Slave configuration parame-
ters will be overwritten by the Master configuration.
