l Synchronous:Pulsesaregeneratedwitharepetitionratebasedonthetime.
If,forinstance,aCycle time issetat15minutes,pulsesaregeneratedat00,
15,30and45minutesofeachhour.Asthepulsecanonlybegeneratedwith
integerscalingfactor,onlydiscretevaluescanbeselected.
Pulse width:Setsthepulseduration,forexamplehowlongthepulsemaintainsa
"High"level.
Cycle time:Setsthepulserepetitionrate.
InSynchronous mode,onlycertaintimescanbeselectedfromthelistasthe
cyclesareinintegerscalingfactorswithrespecttotime.
