ProfiMessage
Thepulsegenerator(red curve)isstartedbythetriggerchannel(blue curve).
Whenaresetsignal(purple curve)isreceived,theoutputissetto"low"andno
furtherpulsesaregenerated.Whentheresetsignalresetsto"Low",thepulsegen-
eratorre-starts(10:25:25)becausethetriggerchannelremainsatahighlevel.In
thesecondexample,nofurtherpulsesaregeneratedbecausethetriggerchannel
hasmeanwhilegoneto"low".
d)
ThetriggeristriggeredbyachannelandhasbeensettoHigh level.Theresetis
alsotriggeredbyachannel,buthasbeensettoEdges (both).
