Delphin ProfiMessage User Manual

ProfiMessage
4.7.14.3.3 Controller2tab

P term affects:SpecifyhowthePtermofthecontrolleristousethecontrol devi-
ation (xd)orimmediatelytheprocess variable (x)asaninputvalue.
D1 term affects:SpecifyhowthefirstDtermofthecontrolleristousethecontrol
deviation (xd)orimmediatelytheprocess variable (x)asaninputvalue.Youcan
alsosetwhichinputvaluesthefirstDtermreactsto.Allnon-effectivevaluesare
takenas0.0.
TheoptionisonlyavailableifthefirstDtermoperateswithoutDelay time.
D2 term affects:SpecifyhowthesecondDtermofthecontrolleristousethecon-
trol deviation (xd)orimmediatelytheprocess variable (x)asaninputvalue.
131
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
