befixedoradaptedtorotationspeed.
In the mode “frequency band adapted to rotation
speed”, this characteristic value can be determined
only when a cyclical digital pulse is connected to a
digital input/counter (e.g. the pulse of a rotating shaft).
This signal provides the basic frequency fn.

Belowisthecorrespondingconfigurationdialogue(Main settingstab):
Example 1:Fixed frequency band.Thecharacteristicvalueprovidesthelargest
amplitudeofthefrequencyspectrumwithintheband100±5Hzor95to105Hz.

