ProfiMessage
Upper section
Active:Enablesordisablesthechannel.
Channel name:Enterameaningfulanduniquenametoidentifythechannel.
Unit:Entertheunitofmeasurement.
Info
Theunitformemorygroupsshouldbeleftas% (default).Occupied
storagespaceisalwaysshownasapercentage.
Location:Informationonthepositionofthesensororsignalsourcecanbeentered
here.
Description:Adescriptionorcommentcanbeenteredhere.Aftercreatingafunc-
tion(softwarechannel),adescriptionofthefunctionappearshere(inEnglish).
Lower section
Copy copiesthesettingsshown,whichyoucanthenadoptinanotherchannelby
inserting .
PreviousorNext:Changestotheconfigurationdialogueofthepreviousornext
channelinthechannelview.Thedialogue'scurrentsettingsareappliedbeforethe
dialoguechanges(theequivalentofclickingonOK ).
OK:Appliesallthesettingsandclosesthedialogue.
Cancel:Cancelstheconfigurationandclosesthedialogue.Thesettingsare
ignoredandnochangesaremadewithinthedevice.
Help:Opensonlinehelp.Therelevanttopicisdisplayedwhereavailable.
Thedateandtimedisplayofthelastsettingchangeforthechannelisdisplayedin
thelowerleftcorner(15.6.2015intheexample).
Tabs in the dialogue's main section
Dependingonthetypeofchannel,differenttabsareavailable.Notallthetabsare
availableforeverychanneltype.Thefollowing(general)tabsareexplainedinthis
sectionastheyareverysimilarfordifferentdevices.
56
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
