ProfiMessage

Status Y K C (clock) Clr (clear) Pre (preset) Q

1 X X X H X L

2 X X X L H H

3 L L X L L Previousstatus

4 H L ↑ L L H

5 L H ↑ L L L

6 H H ↑ L L Toggle

RS flip-flop state table

Status S R

S + set pri-

ority

(clock)

Clr

(clear)

Pre (pre-

set)

1 X X X X H X L

2 X X X X L H H

3 H L X ↑ L L H

4 L H X ↑ L L L

5 H H L ↑ L L L

6 H H H ↑ L L H

7 L L X X L L

Previous

status

InRSflip-flop,thereistheadditionaloptionofSet priority,i.e.thevalueatset

input(S)hasprioritywhenR=H.

D flip-flop

Status D C (clock) Clr (clear) Pre (preset) Q

1 X X H X L

2 X X L H H

3 H ↑ L L H

4 L ↑ L L L

5 L L L L Previousstatus

Delphin Technology AG

Dezember 2015

ProfiMessage Manual
