5 Applied Instructions and Basic Usage
DVP-20PM Application Manual
5-30
API
Applicable model
20PM
15
BMOV
P
P
Transferring values

Bit device Word device
X Y M S K H KnX KnY KnM KnS T C D V Z
S
＊ ＊ ＊ ＊ ＊ ＊ ＊
D
＊ ＊ ＊ ＊ ＊ ＊
n
＊ ＊ ＊ ＊ ＊
 Note: Please refer to specifications for more information about device
ranges.
If KnX/KnY/KnM/KnS is used, it is suggested that X/devices/Y
devices/M device numbers/S device numbers should start from a
number which is a multiple of 16 in the octal numeral system or in the
decimal numeral system, e.g. K1X0 (octal numeral system), K4SY20
(octal numeral system), K1M0 (decimal numeral system), and K4S16
(decimal numeral system).
16-bit instruction (7 steps)
BMOV
Continuity
instruction
BMOVP
Pulse
instruction
32-bit instruction
－ － － －
 Flag: None
Explanation

The instruction is used to transfer the values in registers to new registers. The
values in the n registers starting from S are transferred to the n registers
starting from D. If n is not in the range available, only the values in registers
available will be transferred.

S: Source; D: Destination; n: Length

n is in the range of 1 to 512.
Example 1

When X2.0 is ON, the values in D0~D3 are transferred to D20~D23.
X20
D20 K4
D0
D1
D2
D3
D20
D21
D22
D23
n=4
D0BMOV
Example 2

If users specify KnM and KnY, n in KnM must be the same as n in KnY.
M1000
K1M0 K1Y0 K3
M0
M1
M2
M3
M4
M5
M6
M7
M8
M9
M10
n=3
M11
Y0
Y1
Y2
Y3
Y4
Y5
Y6
Y7
Y10
Y11
Y12
Y13
BMOV
