Delta DVP-20PM User Manual

5 Applied Instructions and Basic Usage
DVP-20PM Application Manual
5-264
5.12.5 High-speed Masking
1. Motion control function block
The motion control function block T_CapMask is used to start high-speed masking. The MaskValue
input pin determines the range which will be masked. After high-speed masking is started, if the relative
difference between the value captured this time and the value captured last time is in the range which
can be masked, the signal which triggers the capture of the value this time will be disregarded.
2. Input pins/Output pins
Input pin
Name Function
Data
type
Setting value Time when a value is valid
Enable
enabled when
there is a
transitio
BOOL True/False -
The motion
control function
block is
n in the
Enable input
pin’s signal
from low to
high.
MaskValue
masked
DWORD K0~2,147,483,647
MaskValue input pin is updated
Range which is
block is exe
When the motion control function
cuted, the value of the
repeatedly.
State output pin
Name Function
Data
type
Time when there is
a transition in an
output pin’s signal
from low to high
Time when there is a transition in an
output pin’s signal from high to low
Busy
The motion
control function
block is being
executed.
BOOL
transition in the
Busy output pi
n’s
signal from low to
high when there is
a transition in the
Enable input pin’s
signal from low to
high.
Busy
output pin’
s signal from hi
gh to low
when there is a transition in the
Error output pin’s signal from low to
high.
 There is a transition in the Busy
output pin’s signal from high to low
when there is a transition in the
Enable input pin’s signal from high
to low.
 There is a
 There is a transition in the
