4 Basic Instructions
4.1 Table of Basic Instructions
 General instructions
Instruction
code
Function Operand
Execution
speed (μs)
Step
Page
number
LD Loading a Form A contact X, Y, M, S, T, C 3.3 3 4-3
LDI Loading a Form B contact X, Y, M, S, T, C 3.3 3 4-3
AND
Connecting a Form A contact in
series
X, Y, M, S, T, C 3.3 3 4-4
ANI
Connecting a Form B contact in
series
X, Y, M, S, T, C 3.3 3 4-4
OR
Connecting a Form A contact in
parallel
X, Y, M, S, T, C 3.3 3 4-5
ORI
Connecting a Form B contact in
parallel
X, Y, M, S, T, C 3.3 3 4-5
ANB Connecting circuit blocks in series None 2.3 3 4-6
ORB Connecting circuit blocks in parallel None 2.3 3 4-7
 Output instructions
Instruction
code
Function Operand
Execution
speed (μs)
Step
Page
number
OUT Driving a coil Y, M, S 7.3 3 4-7
SET Keeping a device ON Y, M, S 5.6 3 4-8
RST Resetting a contact or a register Y, M, S, T, C, D, V, Z 6.9 3 4-8
 Timer and counters
API
Instruction
code
Function Operand
Execution
speed (μs)
Step
Page
number
96 TMR 16-bit timer T-K or T-D 19 5 4-9
97 CNT 16-bit counter C-K or C-D (16 bits) 16 5 4-9
97 DCNT 32-bit counter C-K or C-D (32 bits) 16.5 6 4-10
 Rising-edge/Falling-edge detection instructions
API
Instruction
code
Function Operand
Execution
speed (μs)
Step
Page
number
90 LDP
Starting rising-edge
detection
X, Y, M, S, T, C 12.3 3 4-10
91 LDF
Starting falling-edge
detection
X, Y, M, S, T, C 12.3 3 4-11
92 ANDP
Connecting rising-edge
detection in series
X, Y, M, S, T, C 12.3 3 4-11
93 ANDF
Connecting falling-edge
detection in series
X, Y, M, S, T, C 12.3 3 4-12
94 ORP
Connecting rising-edge
detection in parallel
X, Y, M, S, T, C 12.6 3 4-12
95 ORF
Connecting falling-edge
detection in parallel
X, Y, M, S, T, C 12.6 3 4-13
DVP-20PM Application Manual
4-1
